Product Summary
The DSPIC30F4011-30I/P is an IGBT power module.
Parametrics
DSPIC30F4011-30I/P absolute maximum ratings: (1)Program Memory Size 48KB (16K x 24); (2)RAM Size 2K x 8; (3)Number of I /O 30; (4)Package / Case 40-DIP (0.600, 15.24mm) ; (5)Speed 30 MIPs; (6)Oscillator Type Internal; (7)Packaging Tube; (8)Program Memory Type FLASH; (9)EEPROM Size 1K x 8; (10)Core Processor dsPIC; (11)Data Converters A/D 9x10b; (12)Core Size 16-Bit ; (13)Operating Temperature -40℃ ~ 85℃; (14)Connectivity CAN, I²C, SPI, UART/USART; (15)Voltage - Supply (Vcc/Vdd) 2.5 V ~ 5.5 V; (16)Lead Free Status Lead Free; (17)RoHS Status RoHS Compliant.
Features
DSPIC30F4011-30I/P features: (1)Modified Harvard architecture; (2)C compiler optimized instruction set architecture; (3)84 base instructions with flexible addressing modes; (4)24-bit wide instructions, 16-bit wide data path; (5)16 x 16-bit working register array; (6)Up to 30 MIPs operation: - DC to 40 MHz external clock input - 4 MHz-10 MHz oscillator input with PLL active; (7)Peripheral and External interrupt sources; (8)8 user selectable priority levels for each interrupt; (9)4 processor exceptions and software traps; (10)Primary and Alternate interrupt Vector Tables DSP Engine.
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DSPIC30F4011-30I/P |
Microchip Technology |
Digital Signal Processors & Controllers (DSP, DSC) 16bit Signal Cntrlr |
Data Sheet |
|
|
||||||||||||
 |
DSPIC30F4011-30I/PT |
Microchip Technology |
Digital Signal Processors & Controllers (DSP, DSC) 16 Bit MCU/DSP 30M 48KB FL |
Data Sheet |
|
|
||||||||||||
