Product Summary

The LM311P is a differential comparator with strobe. The LM311P is a single high-speed voltage comparator. The LM311P is designed to operate from a wide range of power-supply voltages, including ±15-V supplies for operational amplifiers and 5-V supplies for logic systems. The output levels of the LM311P are compatible with most TTL and MOS circuits. The comparator LM311P is capable of driving lamps or relays and switching voltages up to 50 V at 50 mA. All inputs and outputs can be isolated from system ground.

Parametrics

LM311P absolute maximum ratings: (1)Output Type: Open Collector, Open Drain; (2)Response Time: 0.115 us; (3)Offset Voltage (Max): 7.5 mV; (4)Supply Voltage (Max): 30 V; (5)Supply Voltage (Min): 3.5 V; (6)Supply Current (Max): 7.5 mA; (7)Maximum Operating Temperature: + 70℃; (8)Mounting Style: Through Hole; (9)Package / Case: PDIP-8.

Features

LM311P features: (1)Fast Response Times; (2)Strobe Capability; (3)Maximum Input Bias Current 300 nA; (4)Maximum Input Offset Current 70 nA.

Diagrams

LM311P internal connection
