Product Summary

The IRFD9014 is a 1.3 Watt rated power MOSFET.

Parametrics

IRFD9014 absolute maximum ratings: (1)ID @ TC=25℃ continous drain current: -1.1A; (2)ID @ TC=100℃ continous drain current: -0.80A; (3)gate-source voltage: ±20 V; (4)max. power dissipation: 1.3 W; (5)operating junction and storage temperature range: -65 to 150 ℃; (6)soldering temperature: 300 ℃; (7)Linear derating factor: 0.0083W/℃; (8)Single pulse avalanche energy: 140mJ.

Features

IRFD9014 features: (1)For automatic insertion; (2)Compact, end stackable; (3)Fast switching; (4)Dynamic dv/dt rating; (5)repetitive avalanche rated; (6)P-channel; (7)175℃ operating temperature.

Diagrams

IRFD9014 circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRFD9014
IRFD9014
Vishay/Siliconix
MOSFET P-Chan 60V 1.1 Amp
Data Sheet
0-1800: $0.79
1800-2500: $0.74
2500-5000: $0.73
5000-7500: $0.73
IRFD9014, SiHFD9014
IRFD9014, SiHFD9014
Other

Data Sheet
Negotiable
IRFD9014PBF
IRFD9014PBF
Vishay Semiconductors
MOSFET P-Chan 60V 1.1 Amp
Data Sheet
0-1: $0.55
1-10: $0.42
10-100: $0.37
100-250: $0.32
