P6SMB10CA

Surface Mount TRANSZORB, Transient Voltage Suppressor, SMB, 5.0 W, Excellent clamping capability

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.06~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.06~0.08

PartNumber:: P6SMB10CA

Brand:: Vishay Siliconix - vishay | Pack: SMB | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Apple Chen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-12

From Other Seller

Part Number:P6SMB10CA
US $0.06 - 0.08
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The P6SMB10CA is a Surface Mount TRANSZORB Transient Voltage Suppressor. It is suitable for Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial and telecommunication.

Parametrics

P6SMB10CA absolute maximum ratings: (1)Peak power dissipation with a 10/1000 μs waveform, PPPM: 600 W; (2)Power dissipation on infinite heatsink TA = 50℃, PD: 5.0 W; (3)Peak forward surge current 8.3 ms single half sine-wave uni-directional only, IFSM: 100 A; (4)Operating junction and storage temperature range, TJ, TSTG: - 65 to + 150℃.

Features

P6SMB10CA features: (1)Low profile package; (2)Ideal for automated placement; (3)Glass passivated chip junction; (4)Available in uni-directional and bi-directional; (5)600 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate (duty cycle): 0.01 %; (6)Excellent clamping capability; (7)Very fast response time; (8)Low incremental surge resistance; (9)Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃; (10)Solder dip 260℃, 40 s; (11)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.
