PIC18F2550-I/SP

DIP-28, High-Performance, Enhanced Flash USB Microcontrollers, -0.3V to +7.5V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.68~4.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.68~4.20

PartNumber:: PIC18F2550-I/SP

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Apple Chen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-22

From Other Seller

Part Number:PIC18F2550-I/SP
US $3.68 - 4.20
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC18F2550-I/SP is a 40-Pin High-Performance, Enhanced Flash USB Microcontroller.

Parametrics

PIC18F2550-I/SP absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD, MCLR and RA4): -0.3V to (VDD + 0.3V); (4)Voltage on VDD with respect to VSS: -0.3V to +7.5V; (5)Voltage on MCLR with respect to VSS: 0V to +13.25V; (6)Total power dissipation: 1.0W; (7)Maximum current out of VSS pin: 300 mA; (8)Maximum current into VDD pin: 250 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (10)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by all ports: 200 mA; (14)Maximum current sourced by all ports: 200 mA.

Features

PIC18F2550-I/SP features: (1)USB V2.0 Compliant SIE; (2)Low-speed (1.5 Mb/s) and full-speed (12 Mb/s); (3)Supports control, interrupt, isochronous and bulk transfers; (4)Supports up to 32 endpoints (16 bidirectional); (5)1-Kbyte dual access RAM for USB; (6)On-board USB transceiver with on-chip voltage regulator; (7)Interface for off-chip USB transceiver; (8)Streaming Parallel Port (SPP) for USB streaming transfers (40/44-pin devices only).
