TIP41C

power transistor, complementary silicon, 6A, 262.5 mJ, 65 W, TO-220

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.38~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.38~0.50

PartNumber:: TIP41C

Brand:: Fairchild Semiconductor - Fairchild | Pack: TO | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Apple Chen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-23

From Other Seller

Part Number:TIP41C
US $0.38 - 0.50
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TIP41C is a power transistor complementary silicon.

Parametrics

TIP41C absolute maximum ratings: (1)Collector-Base Voltage (Ie=0) VCBO: 140 V; (2)Collector-Emitter Voltage (Ib=0) VCEO: 100 V; (3)Emitter-base voltage (reverse) VEBO: 5 V; (4)Continuous collector current IC: 6 A; (5)Peak collector current (max 300μs, duty cycle 2%) ICM: 10 A; (6)Continuous base current IB 3 A; (7)Continuous device dissipation at max 25℃ case temperature Ptot: 65 W; (8)Continuous device dissipation at max 25℃ free air temperature Ptot: 2 W; (9)Unclamped inductive load energy LIC: 2 62.5 mJ; (10)Operating junction temperature range Tj: -65 to+150℃; (11)Storage temperature range Tstg: -65 to+150℃; (12)Lead temperature 3.2 mm from case for 10 seconds TL: 250 ℃.

Features

TIP41C features: (1)65 W at 25℃ Case Temperature; (2)6A Continuous Collector Current; (3)10A Peak Collector Current; (4)100V Collector-Emitter Voltage; (5)Isolated transistor package available on request; (6)Custom selections possible.
