Product Summary

The LA76810A is a monolithic linear IC for PAL/NTSC color television sets VIF/SIF/Y/deflection 1chip IC.

Parametrics

LA76810A absolute maximum ratings: (1)Maximum supply voltage: 7.0 V; (2)Maximum supply current: 25 mA; (3)I25 max: 35 mA; (4)Allowable power dissipation Pd max Ta ≤ 65℃: 1.6 W; (5)Operating temperature Topg: -10 to +65 ℃; (6)Storage temperature Tstg: -55 to +150 ℃.

Features

LA76810A features: (1)VIF/SIF/Y/Deflection Implemented in a 1chip; (2)I2C Bus Control.
